uBLOX MAX-M8Q GPS Breakout for Active Antennas
uBLOX MAX-M8C Pico GPS Breakout with Chip Antenna $26.95
z(DISCONTINUED) uBLOX MAX-M8Q 5V SAW/LNA GPS Breakout With Sarantel Antenna $54.95
UPU-uBLOX M8Q3A SMA

uBLOX MAX-M8Q GPS Breakout for Active Antennas

Be the first to review

$33.95

This is an assembled breakout board with a uBLOX MAX-M8Q-10 module and SMA female connector suitable for connecting to a suitable active patch antenna (See related products).



Suitable for HAB Usage Max Altitude 50,000 meters / 164041 feet in Flight Mode.



The board is constructed on 1.6mm PCB and features a PPS LED and Supercap for retaining settings through power cycles. Improved power filtering over previous versions.



On the header are TX, RX, TP (PPS Output), 3V Supply (2.7V to 3.6V), I2C SDA/SCL and GND.



The MAX-M8Q delivers all the benefits of the u-blox 8 GPS platform in a more compact form factor than ever before: high-sensitivity, intelligent power management.



Supporting temperatures down to -40’C and featuring a TCXO for better power saving and quicker startup the MAX M8Q is an ideal module.



As per the data sheets the MAX M8Q can use upto 22mA under aquisition (5mA in power save mode once tracking).



The breakout has the following dimensions : 22mmx22mmx1.6mm approximately.



The default baud rate is 9600bps.

SKU: UPU-uBLOX M8Q3A SMA Category: Tags: , , ,
